  1. Emergency Intercom JR313-SC-4G
Emergency Intercom JR313-SC-4G

Emergency Intercom JR313-SC-4G

  • Robust cold-rolled steel housing
  • IP55-IP65 Waterproof rating
  • Advanced noise reduction technology for HD calls
  • Corrosion-resistant hardware
  • CE, FCC, RoHS, IK10, IP65, ISO9001 standards
Get Pricing/info Download
Top
Main Features
Applications
Technical Specifications
Application Scenarios
Contact Us

Main Features

Housed in cold rolled steel box and manufactured to high standards, these telephones offer enhanced resistance to vandalism and ensure reliable communication at all times.

Additionally, this series of phones has been tested in salt spray and is highly durable in humid and corrosive environments. Extremely easy to install, the cable entrance is located at the back of the phone to prevent artificial damage.

Ideal for parking lots, lifts/elevators, hotels, doorways, railway/metro platforms, hospitals, police stations, ATMs, stadiums, and outdoor building etc.


  • 4G wireless communication with remote configuration
  • Hands-free operation with a single vandal-resistant metal button for emergency calls
  • Equipped with an LED light that blinks during incoming calls
  • Noise-cancelling microphone
  • Built-in 2W speaker
  • Red color (other colors available on request)
  • On wall-mounted design, with an M16 cable gland on the bottom shell

Applications

Insert the SIM card into the 4G phone and connect to the operator's network to make calls

JR313-SC-4G APPLICATIONS

Product Video

Technical Specifications

4G Specifications
Power supply 12V DC
Adapter input 7.4 V-12V DC
Power consumption Idle 0.3W / Working 1.5W
Communication mode 4G
Working frequency Depends on modules
Ringing tone 90 dB (A) @ 1 meter
Configuration method Remote configuration via SMS, allows management from a central location
Configuration Remote monitoring / Auto-dial numbers
Time out Enforces a fixed call maximum time limit of 6-8 minutes from off-hook, configurably
Diagnostic function Low battery voltage, weak signal, speaker volume, microphone volume can be reported via message
Antenna Quad-band SMA male, externally mounted with 2 m cable
Environment temperature Operating temperature -40˚C to 65˚C; Storage temperature -40°C to 75°C
M.T.B.F. Exceeds 50,000 hours under normal operating conditions
4G Module EC25
Module EC25-E EC25-EU / EUX EC25-J EC25-V
Region EMEA/Korea/Thailand/India EMEA/Thailand Japanese America Verizon
Frequency
LTE-FDD B1/B3/B5/B7/B8/B20 B1/B3/B7/B8/B20/B28A B1/B3/B8/B18/B19/B26 B4/B13
LTE-TDD B38/B40/B41 B38/B40/B41 B41 /
WCDMA B38/B40/B41 B1/B8 B1/B6/B8/B19 /
GSM/EDGE B3/B8 B3/B8 / /
GNSS GPS/GLONASS/BeiDou (Compass)/
Galileo/QZSS (option)
GPS/GLONASS/BeiDou (Compass)/
Galileo/QZSS (option)
GPS/GLONASS/BeiDou (Compass)/
Galileo/QZSS (option)
GPS/GLONASS/BeiDou (Compass)/
Galileo/QZSS (option)
Module EC25-A EC25-AF / AFX / AFXD (Data-only) EC25-AUX EC25-MX
Region North America North America Latin America/Australia/New Zealand Mexico
Frequency
LTE-FDD B2/B4/B12 B2/B4/B5/B12/B13/B14/B66/B71 B1/ B2/B3/B4/B5/B7/B8/B28 B2/B4/B5/B7/B28/B66
LTE-TDD / / B40 /
WCDMA B2/B4/B5 B2/B4/B5 B1/B2/B4/B5/B8 B2/B4/B5
GSM/EDGE / / B2/B3/B5/B8 /
GNSS GPS/GLONASS/BeiDou (Compass)/
Galileo/QZSS (option)
GPS/GLONASS/BeiDou (Compass)/
Galileo/QZSS (option)
GPS/GLONASS/BeiDou (Compass)/
Galileo/QZSS (option)
/

Product Application

Metro

Metro

Airport

Airport

Platform

Platform

Business center

Business center

Highway

Highway

Hospital

Hospital

Bank

Bank

School

School

Optional Accessories

Multiple Options Available Button

Button

Broadcast Horn JR-HSA-10/20/25/30/35

JR-HSA-10/20/25/30/35

LED Beacon Light JR-LP-02

JR-LP-02

Dimensions

JR313-SC-4G Dimensions
Package
Unit size 200*140*50 (mm)
Shipping dimensions 340*235*165 (mm)
Packaging materials Foam padding, carton
Weight Gross weight: 2 kg / Net weight: 1.5 kg
