| SIP Specifications |
| Power supply |
Power over ethernet |
| Power |
9.0 watts, 12~24V DC |
| SIP protocol |
SIP 2.0 (RFC3261) |
| Network port parameters |
WAN Port: 10/100Base- T RJ-45 for LAN, Auto MDIX，LAN Port: 10/100Base- T RJ-45 for PC, Auto MDIX |
| Voice coders |
G.711 A/U, G.722 8000/16000, G.723, G.729, G.726 |
| Communication mode |
Full duplex |
| Ringing volume |
90~95 dB (A) @ 1 meter |
| Data protocols |
IPv4, TCP, UDP, ICMP, ARP, RTP, SRTP, ONVIF, SNMPv1, RTCP-XR, 802.1x, Static IP/DHCP IP Assignment,
IEEE 802.1p/Q, QoS/ToS, HTTP/HTTPS/DHCP, NTP, FTP/TFTP, CDP/LLDP VLAN Configuration, LDAP |
| Technical Specifications |
| Built-in auto-dial, 2-way hands-free communication with built-in speaker and microphone, standard RJ45 connector. |
| Auto-answer allows security to monitor and initiate calls with Emergency Phone. |
| Vandal resistant brushed stainless steel face-plate and metal button, Circuit boards are conformal coated for water protection. |
| Offers direct connection to LAN or WAN via RJ45 connector, including Power-Over-Ethernet (POE) standard. |
| Easy Configuration |
Intuitive web pages held within the telephone can be accessed over the network using a browser such as Internet Explorer™ to view monitor
and change settings within the telephone. |
| 24/7 Availability |
Telephones with memory buttons have an automatic call divert facility as standard, so that if a number (or URL) is not available then to up to
20 alternatives can be dialled automatically. |
| Remote Control |
| Two outputs provide the ability to control external beacons, sounders, CCTV triggering andgate control. |
| Four inputs allow for the monitoring of sensors which can initiate email or Syslog messaging. |
| Global Application |
| Equipped with national telephone call tones enabling seamless operation across the globe, and giving the user recognisable comfort tones. |
| Weather and Vandal Resistance is Standard |
| The telephones are housed within our standard enclosures offering proven high levels of unit integrity and delivering a robust solution. |
| Multicast (Only applicable to hands-free products) |
Allows a single audio stream to be received by multiple endpoints simultaneously, to achieve multi-point paging or Public Address
functionality over IP (Requires amulticast compliant SIP server). |
| 8 definable multicast address ranges, with individual priority levels, for zoning. Assignable rely outputs and splash tones. |
| Audio Path Testing |
| Allows remote testing of handsets, microphones and speakers, to verify that a phone is functioning acoustically. |
| Can be run on demand or on a scheduled basis, reporting its results via Syslog and / or email. |
| DTMF (dual tone multi-frequency) |
| The phone s 2 relays can be activated remotely using DTMF codes. |
| Lighting |
| LED Blue Light, 209 lumens peak, 78 flashes per minute, 70% of initial lumens after 50,000 hours of operation. |
| Coating |
| High-gloss, multi-layer, corrosion-inhibitive, system with resistance to graffiti protection. |
| Mounting |
| Mounts into concrete foundation using included hardware (shipped in advance). Mounting options available for pre-poured parking decks. |
